Name: D1105 Engine Assembly for Kubota Excavator Engine
Brand: Guangzhou Lanxin Machinery Equipment Co., Ltd
SKU: D1105
Price: 4750.00 USD
Availability: InStock

Home > products > Construction Engine >

D1105 Engine Assembly for Kubota Excavator Engine

Kubota excavator engine assembly

D1105 construction engine

Kubota D1105 engine replacement

Place of Origin:

China

Brand Name:

Kubota

Model Number:

D1105

Chat Now

Request A Quote

Product Details

Product Name:

Kubota D1105 Engine

Size:

A Standard Size

Quality:

High-Quality

Cooling System:

Water-cooled

Shipment:

DHL FEDEX TNT EMS

Condition:

New

Fuelinjection:

Direct Injection

Delivery:

3-7 Working Days

Highlight:

Kubota excavator engine assembly

D1105 construction engine

Kubota D1105 engine replacement

Payment & Shipping Terms

Minimum Order Quantity

Price

$4000 - $5500

Packaging Details

Wooden Box

Delivery Time

3-7 work days

Payment Terms

T/T,D/P,D/A,L/C

Supply Ability

V2607 Engine Assembly 4 Cylinder for Kubota Excavator

Chat Now

D1105 Engine Assembly for Kubota Excavator Engine

Chat Now

TAD1352VE Diesel Engine Assembly 315kW 12.78L 6 Cylinder for Vo-lvo Penta Excavator

Chat Now

video

R4105ZD Ricardo S Diesel Engine 1500 rmin 66 KW for Weifang Generator Genset

Chat Now

86--18688416585

Sales02@lanxinmachinery.com

86--18688416585

Chat Now

Product Description

Kubota D1105 Engine Assembly for Excavator Applications

Product Overview

Complete Kubota D1105 diesel engine assembly designed for excavators, tractors, and forklifts. This three-cylinder, water-cooled engine delivers reliable performance with 1.123L displacement and 18.5 kW output at 3000 rpm.

Key Features

Complete Kubota D1105 engine assembly quoted under multiple part numbers
Three-cylinder configuration with 78.0 x 78.4 mm bore and stroke
Naturally aspirated 18.5 kW (24.8 hp) at 3000 rpm operation
MD type mini injection pump with glow plug system
Direct fit for Kubota excavators, tractors, and forklifts

Technical Specifications

Item	Specification
Product Name	Complete Diesel Engine Assembly
Engine Model	Kubota D1105 series (multiple build variants)
Assembly Numbers	1J905-62000; 1J351-25000; 1J351-33000; 1G324-82000; 1JT0780
Configuration	Vertical, water-cooled, 4-cycle diesel; 3 cylinders inline
Bore x Stroke	78.0 x 78.4 mm (3.07 x 3.09 in)
Displacement	1.123 L (1123 cc / 68.53 cu in)
Rated Output	Naturally aspirated: 18.5-18.7 kW at 3000 rpm; D1105-T turbo: 24.5 kW
Fuel System	MD type mini fuel injection pump with mechanical or electronic control
Weight	Approximately 93 kg
Machine Fitment	Kubota KX36-2, KX41, KX41-2, KX71, U25S excavators; F2400, F2560E, F2880F tractors; forklifts
Condition	New units available; used engines traded from USD 950-1,300

Cross Compatibility & Important Notes

D1105 vs D1105-T Are Different Engines
The naturally aspirated D1105 produces 18.5 kW while the turbocharged D1105-T produces 24.5 kW with different internal components and injection settings.

Suffix Determines Fuel System Type
EF02, EF09, ET03, E3B, B, BE, K and CR-T variants indicate different emission and control systems. Early builds use mechanical pumps while D1105-K features electronic control for EPA Tier 4 compliance.

Cylinder Count Identification
Kubota model codes begin with cylinder count: Z for two cylinders, D for three cylinders, V for four cylinders. These are distinct engine families with different specifications.

Compatible Part Numbers

Category	Replaceable Part Numbers & Compatible Models
Assembly Numbers	1J905-62000; 1J351-25000; 1J351-33000; 1G324-82000; 1JT0780
Cylinder Head Numbers	1J096-03040; 1G053-03040; 1G065-03044; 16032-03042; 16261-03040
Injector Numbers	1G065-53900; 1G065-53902
Compatible Machines	Kubota KX36-2, KX41, KX41-2, KX71, U25S excavators; F2400, F2560E, F2880F tractors; forklifts; compact loaders; generator sets
